The laser cleaning machine removes rust, oxide layers, paint, and other contaminants without any physical contact, protecting the surface of the workpiece while significantly improving cleaning speed and efficiency.
This process requires no chemical solvents or abrasive materials, producing no wastewater or secondary pollution. It is energy-efficient and nearly maintenance-free, making it an environmentally friendly and sustainable cleaning solution.
With adjustable laser power, scanning speed, and frequency, the machine can be precisely controlled to clean a wide range of materials and contamination types. This ensures consistent results and adaptability for different industrial applications.
Main Features
- Ultra-Fast & Non-Contact Cleaning – Say goodbye to rust, paint, grease, and stubborn contaminants. Our cutting-edge laser technology cleans surfaces instantly, without touching or damaging the material. Experience precision cleaning like never before, with unmatched speed and efficiency.
- Eco-Friendly, Safe & Cost-Saving – Traditional cleaning methods rely on harsh chemicals, abrasives, and messy processes. Our laser solution eliminates waste, avoids harmful substances, and drastically reduces energy consumption. Safe for both your operators and the environment, it’s the sustainable cleaning solution for modern industries.
- Integrated with an intelligent control system, auto-focus cutting head, and reliable water-cooling design, the machine guarantees consistent performance, easy operation, and long service life under continuous workloads.
Precision for perfect results
Little maintenance required for greater productivity
Little maintenance required for greater productivity
Quality and reliability over time
Simple and easy to program
Reduced space required
Wide range of accessories and configurations
Extremely versatile
Parameter
| Power | 1000w 1500W 2000W 3000W |
| Supply voltage | Single-phase 220V ± 10%, 50 / 60Hz AC |
| Work environment humidity | ≤80% |
| Fiber length | 8m-10m (customizable） |
| Scanning width | 10-60mm |
| Laser average power | ≥200W |
| Power adjustment range (%) | 10-100(Adjustable gradient) |
| Focus spot diameter | 0.08mm |
| Center wavelength | 1080nm |
| Peak power maximum | 10kw |
| cooling | Air cooling/water cooling |
| Air cooling/water cooling | Manual / Based on galvanometric laser scanner |
| Manipulator weight | 2.75KG |
| Machine Weight | 200KG |
Watch the SPCL-01 in action
Application sectors
Problems in traditional industrial cleaning
Mechanical friction cleaning
High cleanliness, but easy to damage the substrate
Chemical corrosion cleaning
Stress-free cleaning, but serious cleaning
Liquid solid spray cleaning
High flexibility, but high cost. Complicated waste liquid treatment is required
High Frequency Ultrasonic cleaning
Good cleaning effect but limited cleaning size
